When the processor requests data, the two adjacent levels at a time. A block
cache controller first checks the cache. is the fixed-size chunk of data that the
If the data is found, a cache hit occurs, cache transfers between itself and other
and the data is quickly delivered to the memory levels. Chapter One: Computer architecture
processor. If not, a cache miss occurs,
FOR ONLINE READING ONLY
and the cache controller then checks the Cache line: A unit of data storage within
main memory. If the data is found in main the cache. It acts like a container that
memory, a main memory hit occurs, and holds a block and is specifically designed
the data is transferred to the cache and for efficient data transfer between the
then to the processor. If the data is not cache and other memory levels.
in the main memory, a main memory
miss occurs. The data is retrieved from Cache hit: An event in which specific
storage, transferred to the main memory, data or instructions are searched and
then to the cache, and finally delivered found available in the accessed cache
to the processor. memory. In this scenario, the cache
transfers (copies) the requested data to
Cache the processor.
CPU control
logic
Cache miss: Event in which specific data
or instructions is searched and not found

Block in the accessed cache memory. In this
scenario, the data is fetched from lower
levels and transferred to the processor.

Block is Hit rate: the percentage of times the data
transferred
is found in the cache without needing to
access lower levels. A higher hit rate
indicates efficient data retrieval.

Totalhits
Hitrate =
Totalhits+Totalmisses
Figure 1.39: Memory interfacing between
cache memory and main Miss rate: the percentage of times the
memory data is not found in the cache and needs
to be fetched from lower levels. A lower
Memory hierarchy and interfacing are miss rate is desirable.
enabled by the following key concepts;
Unit of information transfer: Memory Missrate = Totalmisses
is organised into fixed-size blocks. A Totalhits+Totalmisses
memory hierarchy can consist of multiple Miss penalty: the extra time it takes to
levels, but data is copied between only access data from a lower level compared

39
