Current electricity
circuit to an equivalent resistance using At this point, the bridge circuit is
parallel and series formulae. However, balanced, and therefore,
if you observe the circuit carefully, you P R
realize that, the resistors on one side of Q = X V ,
the joint resistor, J, are in the same ratio
as the resistor on the other side of J. That which means,
FOR ONLINE READING ONLY
is, QR
X = V
P 5 R 10 P
and 5.
Q 1 X 2 Performing activity 2.7 gives more
understanding on Wheatstone bridge.
P R
Therefore, = .
Q X
Activity 2.7
A bridge circuit that has this property is
said to be a balanced Wheatstone bridge. Aim: To determine the resistance
Now, suppose the resistor J, is removed of an unknown resistor X,
from the circuit so that resistor P, is in using a Wheatstone bridge.
series with resistor R, and resistor Q is Materials: zero centred galvanometer,
in series with resistor X. Moreover, the a dry cell, decade resistance
resistors P and R are in parallel with box R , known resistors P
V
resistors Q and X. Therefore, the voltages and Q (ranging from 1
at points E and F are the same. Since, Ω to10 Ω), the unknown
P R resistor X whose values
= , range from 4 to 10 ,
Q X
a switch, and connecting
the voltage drop at P is the same as the wires
voltage drop at Q, meaning that voltage Procedure
at point B (V is the same as voltage at 1. Use the materials provided to set
)
B
point C (V C ).This means the potential up the Wheatstone bridge circuit as
difference between points B and C is zero. shown in Figure 2.29.
Thus, when the resistor J is connected, 2. Switch ON the circuit to allow
current through it is zero. That is, when current to flow through the circuit.
the bridge circuit is balanced, I = 0 A. Ensure that the amount of current
J
Suppose a resistor J is replaced with a flowing through the galvanometer
galvanometer G as shown in Figure 2.29. does not deflect it out of range.
The variable resistor R can be varied 3. Adjust the resistance, R , until the
,
V
reading on the galvanometer, G
V
to a point where the current through the is zero. At this point the bridge is
galvanometer I = 0 A. balanced.
G
61
